6.1.7 TCP-IP with GPRS Backup with Dial up Backup Configuration
1.0
SELECT SERVICE
PROVIDER
1-PAYMARK
2-Vodafone
3-Black and White
4-2 Degrees
5-Telecom
6-Kore Wireless
7-Global M2M
8-
This parameter specifies the GPRS service Provider. By default 1 is selected for
Paymark SIM card. Press ENTER.
These options are pre-configured and autom
atically configure the terminal to
different SIM providers.
Option 8- Allows you to manually configure the APN
2.0
GPRS USER NAME?
This parameter specifies the GPRS USERNAME. By default this field will be blank.
Press ENTER.
3.0
IP PRIMARY
HOST PORT
33876
This parameter specifies the Primary TCP/IP Port Number of Paymark network.
Press ENTER.
4.0
IP SECONDARY
HOST PORT
33876
This parameter specifies the Secondary TCP/IP Port Number of Paymark network.
Press ENTER.
5.0
ENABLE DHCP Y/N
1-YES 2-NO
Press the corresponding number key and press ENTER to set the IP address for the
terminal.
Option 1 – to allow the terminal to dynamically obtain its IP address and proceed
with step 7.0. Option 1 is selected by default.
Option 2 – to enter in static IP address for the terminal and proceed with step 6.0
NOTE: When configuring the terminal for Static IP address, ensure to
obtain the IP address, subnet mask and default gateway IP address from
your ISP (Internet Service Provider) for connectivity to Paymark network.
6.0
TERM IP ADDRESS
XXX.XXX.XXX.XXX
Enter in the static IP address for the terminal.
Example: 192.10.1.14
Note: Press the FUNC key to insert a dot in between numbers.
7.0
SUBNET MASK
XXX.XXX.XXX.XXX
Enter in the subnet mask for the static IP address.
Example: 255.255.255.0
8.0
GATEWAY IP ADDR
XXX.XXX.XXX.XXX
Enter in the gateway IP address to forward the packets from.
Example: 192.10.1.1
