NITRO INGENICO ICT250 AND IWL252 2015 PAYMARK SOFTWARE OPERATING GUIDE Version 1.0
15.6 CONNECTION
All connections are on the rear of the terminal protected by a cover.
15.7 OPENING THE CABLE COVER
o Unclip the cover by pushing simultaneously on the clips with your nails
figure as shown on the figure here below.
o Lift the cover rearward to remove it, as shown by arrows on the figure.

Ingenico iCT250 Specifications

General

Memory	16 MB RAM, 128 MB Flash
Card Readers	Magnetic stripe, Smart card, Contactless
Operating System	Telium 2
Connectivity	Ethernet
Security	PCI PTS 3.x certified
Printer	Integrated thermal printer
Supported Cards	Visa, Mastercard, American Express, Discover
Display	128x64 pixel LCD, Backlit
Power Supply	External power adapter
