Follow the installation instructions shown below:
o Plug:
Power lead
Telephone line
Ethernet cable
Serial link RS232 cable
o Install caps in the lead-through (as indicated on the figure).
o Close the compartment with the cable cover provided, like the
procedure describe at chapter 7.7.
The power adapter and Figure 8 cable that connects the terminal to a 100 -
240V power outlet:
