Function Parameter Table MD320/MD320N User Manual
70
Function
code
Name LED display Set range
Minim-
um unit
Factory
default
value
Modication
description
F0-05
Auxiliary
Frequency
source
Y range
selection
Y range
selection
0: Relative to maximum
frequency
1: Relative to frequency source
X
1 0
☆
F0-06
Auxiliary
Frequency
source Y
Auxiliary
Frequency
source Y
0%
～
100% 1% 100%
☆
F0-07
Frequency
source
selection
Frequency
source
selection
0: Main frequency source X
1: Main frequency source X plus
auxiliary frequency source Y
2: Swi tch i ng b e twe en ma in
f r e q u e n c y s o u r c e X a n d
auxiliary frequency source Y
3: Swi tch i ng b e twe en ma in
frequency source X and (main
f r e q u e n c y s o u r c e X p l u s
auxiliary frequency source Y)
4: Swi tch i ng b e twe en ma in
frequency source Y and (main
f r e q u e n c y s o u r c e X p l u s
auxiliary frequency source Y)
1 0
☆
F0-08
Preset
frequency
Preset
frequency
0.00Hz ~ maximum frequency
F0-10
0.01Hz 50.00Hz
☆
F0-09
Running
direction
Running
direction
0: Direction is consistent
1: Direction is reverse
1 0
★
F0-10
Maximum
frequency
Maximum
frequency
50.00Hz
～
300.00Hz 1 50Hz
★
F0-11
Frequency
source upper
limit
Frequency
source upper
limit
0: F0-12 setup
1: AI1
2: AI2
3: AI3
4: PULSE setup
5: communication setup
1 0
★
F0-12
Frequency
upper limit
Frequency
upper limit
Frequency lower limit of F0-14 ~
maximum frequency of F0-10
0.01Hz 50.00Hz
☆
F0-13
F r e q u e n c y
u p p e r l i m i t
offset
Frequency
upper limit
offset
0.00Hz ~ maximum frequency of
F0-10
0.01Hz 0.00Hz
☆
F0-14
Frequency
lower limit
Frequency
lower limit
0.00Hz
～
Frequency upper limit
of F0-12
0.01Hz 0.00Hz
☆
F0-15
Carrier
frequency
Carrier
frequency
0.5kHz
～
16.0kHz 0.1kHz
Model
dependent
☆
