Front & Rear Panels
—Continued
J
TAPE IN/OUT (34)
These analog inputs and outputs can be used to con-
nect a cassette recorder, Mini Disc recorder, or other
recorder with analog inputs and outputs.
K
MONITOR OUT (27)
This S-Video or composite video output can be con-
nected to the video input on your TV or projector.
L
ZONE 2 OUT (84)
These composite video and analog audio outputs
can be used to feed a TV and an integrated amp in
Zone 2.
M
DVD IN (28)
These S-Video, composite video, and analog audio
inputs can be used to connect a DVD player.
N
VIDEO 1 & 2 IN/OUT (29, 31)
These S-Video, composite video, and analog audio
inputs and outputs can be used to connect one or
two video recorders (e.g., VCRs).
O
VIDEO 3 & 4 IN (31)
These S-Video, composite video, and analog audio
inputs can be used to connect one or two video
sources (e.g., cable TV, satellite TV, or a set-top
box).
P
COMPONENT VIDEO OUTPUT (27)
This component video output can be used to con-
nect a TV or projector with a component video
input.
Q
COMPONENT VIDEO INPUT 1 & 2 (28, 30, 32)
These component video inputs can be used to con-
nect one or two AV components with component
video outputs, such as a DVD player.
R
ETHERNET (Net-Tune) (76)
This port is for connecting the DTR-8.4 to your
Ethernet network (i.e., router or switch) for use with
Net-Tune (i.e., Internet radio and MP3 and WAV
playback).
S
SPEAKERS (23)
These terminal posts are for connecting your speak-
ers. The SURR BACK/ZONE 2 terminals can be
used with surround back speakers in the main room
or speakers in another room (Zone 2).
T
RS232 (37)
This port is for connecting the DTR-8.4 to home
automation and external controllers.
U
IR IN/OUT (85)
If you want to use the remote controller to control
the DTR-8.4 from Zone 2, or if the DTR-8.4 is
installed in a cabinet and the line of sight between
the DTR-8.4 and the remote controller is obstructed,
a commercially available IR receiver can be con-
nected to the IR IN. A commercially available IR
emitter can be connected to the IR OUT to pass the
IR signals along to another AV component.
V
12V TRIGGER OUT ZONE 2/A/B (68, 85)
These outputs can be connected to the 12-volt trig-
ger inputs on other components. They output 12
volts (100 milliamperes max). The ZONE 2 TRIG-
GER OUT outputs 12 volts while the DTR-8.4 is in
Zone 2 mode. The A and B outputs can be assigned
to input sources, in which case, the assigned trigger
output outputs 12 volts while the input source is
selected.
W
REMOTE CONTROL (36)
This (Remote Interactive) socket can be con-
nected to the socket on another Integra/Onkyo
AV component. The DTR-8.4’s remote controller
can then be used to control that component. To use
, you must make an analog RCA/phono audio
connection between the DTR-8.4 and the other AV
component, even if they are connected digitally.
X
AC INLET (37)
The supplied power cord should be connected here.
Y
AC OUTLETS (37)
These switched AC outlets can be used to supply
power to other AV components. The connector type
depends on the country in which you purchased
your DTR-8.4.
Z
Grounding screw (35)
This screw is for connecting a turntable’s ground
wire.
