Connecting the DTR-8.4 —Continued
Video Connections
You only need to use one of the following connection
methods.
If you just want to listen to the audio from your TV via
the DTR-8.4 with surround sound, no video connections
are necessary, just make an audio connection.
■ Using Composite Video
Use a composite video cable to connect the DTR-8.4’s
VIDEO VIDEO 3 or 4 IN to the composite video output
on your video source, as shown.
■ Using S-Video
Use an S-Video cable to connect the DTR-8.4’s
S VIDEO VIDEO 3 or 4 IN to the S-Video output on
your video source, as shown.
■ Using Component Video
Use a component video cable to connect the DTR-8.4’s
COMPONENT VIDEO INPUT 1 or 2 to the component
video output on your video source, as shown.
Audio Connections
■ Using Coaxial or Optical Connections
• Use a coaxial digital audio cable to connect the
DTR-8.4’s DIGITAL IN COAX , 2, or 3 to the coaxial
output on your video source, as shown.
OR
• Use an optical digital audio cable to connect the
DTR-8.4’s DIGITAL IN OPT 3 to the optical output
on your video source, as shown.
Notes:
•You may need to change the digital input-to-input
source assignments (see page 45).
•To connect the DTR-8.4 to an LD player’s AC-3RF
output, you need a commercially available demodula-
tor.
Connecting Other Video Sources—
TV, Satellite, Cable, Set-top box, LD
Player, etc.
