Required Hardware: One Null Modem Cable and a Host Unit with a serial COM port
(system used to flash the SUT).
Here is the sequence of events necessary to program the H8.
1. Extract all files (keep them in the same folder) to a single directory of your
choice on the host machine or on a floppy disk (recommended).
2. Connect a NULL modem cable to the serial ports of each platform (host and
unit to be flashed).
3. Boot host in DOS mode.
4. Set the jumpers on the board per Table 20
.
5. Power on the board and press the PWR button.
6. From the host directory where you extracted the files, run the following
command line:
KSCFLAxx ksc.bin / Remote
where xx refers KSC flash utility version number.
7. This file will program ksc.bin to the KSC flash memory through the remote
(Null modem cable).
8. Follow the instructions provided by the flash utility.
9. After successful programming of the KSC, switch-off board power and move
all three jumpers back to their default setting. The program assumes the host
computer is using serial port 1.
Note: Make sure the board is not powered on, and the power supply is disconnected before
moving any of the jumpers.
Table 24. H8 Programming Jumpers
Signals
SMC_INITCLK
(H8 NMI)
Serial Port
(TXD)
Serial Port
(RXD)
Jumper
Setting
Default
(1-2) (1-2) (1-2)
For KSC
programming
Open
Short pin
2 and 3
Short pin
2 and 3
Jumper ID #
J9G1 J8C6 J8C7
5.4 Key Jumpers
The jumpers used for programming SPI and H8 are indicated in Figure 14.
