Development Kit Features
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
User Guide March 2011
24 Document Number: 325208-001
Feature
Development Board
Implementation
Description
Soft
Audio/Soft
Modem
Intel
®
High Definition Audio MDC
header
Support via interposer; use Mott
Canyon 4 daughter card (support
via sideband cable).
SATA 6x SATA ports
Two ports capable of 6 GT/s; one
Direct Connect connector, one cable
connect, one SATA ODD connector,
two eSATA connectors, and one to
dock
USB2.0 14x USB 2.0/1.1 ports
One Dual Stacked Dual and DP
Connector, one Dual USB connector
on RJ45, eight ports available as
FPIOs. Two ports routed to USB2/3
Dual Stacked connector; optional
Routing to Docking for USB Lane 4
Over Current protection provided in
Pairs. Floater OC7# used as
SMC_WAKE_SCI#
LPC 1x LPC slot Includes sideband headers
SMC/KBC
H8S/2117* microcontroller; two PS/2
ports, one scan matrix keyboard
connector
ACPI compliant
Clocks CK505 system clock
Board supports both Buffered mode
and Fully integrated clocking
schemes.
RTC Battery-backed real-time clock
Implementation similar to previous
generation Intel mobile platforms.
Processor
Voltage
Regulator
Intel
®
Mobile Voltage Positioning-7
compliant CPU and graphics voltage
regulators (GFX VRs)
Uses Serial VID interface Manual
Override Option for VIDs not
available on VR controller; uses
Serial VID interface instead of
Parallel VIDs.
3.1 Processor Support
The development board supports the 2nd Generation Intel
®
Core™ processor family in
a 989-pin rPGA package (U3E1), which fits into Socket G2.
The processor features a monolithic die with integrated memory and graphics
controller.
Note: Socket G2 -- Socket 988B specifically meant for 2nd Generation Intel
®
Core™
processor family. It has pins A1, B1 de-populated compared to rPGA 989.
