Intel 6 SERIES

About This Document
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
March 2011 User Guide
Document Number: 325208-001 11
Term Definition
Stub The branch from the bus trunk terminating at the pad of an agent.
Trunk The main connection, excluding interconnect branches, from one end.
System
Management Bus
A two-wire interface through which various system components may
communicate.
Undershoot
The minimum voltage extending below VSS observed for a signal at the
device pad.
VCC (CPU core)
VCC (CPU core) is the core power for the processor. The system bus is
terminated to VCC (CPU core).
Victim
A network that receives a coupled crosstalk signal from another network
is called the victim network.
Table 3 defines acronyms used throughout this document.
Table 3. Acronyms
Acronym Definition
AC Audio Codec
ACPI Advanced Configuration and Power Interface
ADD2 Advanced Digital Display 2
ADD2N Advanced Digital Display 2 Normal
AIC Add-In Card
AMC Audio/Modem Codec.
Intel
®
AMT Intel
®
Advanced Management Technology
ASF Alert Standard Format
AMI* American Megatrends Inc.* (BIOS developer)
ATA Advanced Technology Attachment (disk drive interface)
ATX Advance Technology Extended (motherboard form factor)
BGA Ball Grid Array
BIOS Basic Input/Output System
BLI Backlight Inverter
BPM Break Point Monitor
CK-SSCD Spread Spectrum Differential Clock
CMC Common Mode Choke
CMOS Complementary Metal-Oxide-Semiconductor
CPU Central Processing Unit (processor)
DDI Digital Display Interface
DDR Double Data Rate
