Intel 6 SERIES

Development Board Summary
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
User Guide March 2011
54 Document Number: 325208-001
Table 21. Power On and Reset Button
Item# Description Reference Designator
1 Power Button SW1E1
2 Reset Button SW1E2
3 Processor U3E1
Table 22. Other Development Board Switches
Item# Description
Reference
Designator
Default Switch Settings
1 LID SWITCH SW9H2 (1-2)
2 VIRTUAL DOCKING SW9H1 (1-2)
3 VIRTUAL BATTERY SW9H3 (1-2)
4.5 LEDs
The following LEDs provide status of various functions:
Table 23. Development Board LEDs
Function
Reference
Designator
Page# on the
Schematics for
reference
Indicates CATASTROPHIC ERROR CR1D1 4
DSW CR5G2 71
SYSTEM POWER GOOD CR5H1 71
System in S5 CR5H2 71
System in S4 CR5H3 71
System in S3 COLD CR5H4 71
System in S0 CR5H5 71
System in M0/M3 CR5H6 71
MPC ON/OFF INDICATOR LED CR6D1 24
SATA ACTIVITY CR7G2 19
NUM_LOCK CR9G1 50
CAPS_LOCK CR9G2 50
SCROLL_LOCK CR9G3 50
BIOS_SEL0 CR9E1 47
BIOS_SEL1 CR9E2 47
