Intel 6 SERIES User Manual

Development Kit Features
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
User Guide March 2011
30 Document Number: 325208-001
• DRAMPWROK: Power good signal for DDR.
• APWROK: Indicates that the ME rails to PCH are stable.
• SYS_PWROK: Signal indicates that all platform Power Rails to PCH are stable.
• PLT_RST#: Platform Reset Signal indicated by CR5H1.
3.2.3 PCIe* Support
The development board supports six on-board PCIe (5x1 and 1x4) slots. The Intel 6
Series chipset has a total of eight Gen 2 PCIe ports. By default, four of those IO ports
have been routed to x1 connectors, one to a x4 connector, one to LAN, one to Display
Mini PCIe connector, and one to docking.
Slot 1 and 2 are in-line and close to the PCH. Slots 3 and 4 are in line and close to the
processor. Slot 5 is a x4 slot.
Table 8. PCIe* Ports
PCIe Port Default Destination
Non-Default
Destination
1 PCIe Slot 1 (J6C2) -
2
PCIe Slot 2 (J6D2) (in-line
with Slot 1)
-
3 PCIe Slot 3 (J7C1) -
4 PCIe Slot 4 (J7D2) -
5 PCIe Slot 5 (J6C1) -
6 LAN (EU7M1) PCIe Slot 5 (J6C1)
7 DOCKING (J9C1)
PCIe Slot 5 (J6C1)
PCIe Slot 6 (J8C1)
8
DISPLAY MINI PCIe
Connector(J7M1)
PCIe Slot 5 (J6C1)
DOCKING (J9C1)
More details on the reworks to be done for different destinations of the PCIe ports are
given below.

Intel 6 SERIES Specifications

General

Chipset Series	6 Series
Code Name	Cougar Point
Max # of SATA 3.0 Ports	2
Max # of SATA 2.0 Ports	4
Socket Support	LGA1155
PCI Express Version	2.0
SATA Ports	6
USB Ports	14
Chipset	Intel H61 Express Chipset, Intel H67 Express Chipset, Intel P67 Express Chipset, Intel Z68 Express Chipset
Memory Support	DDR3
RAID Support	Yes
Integrated Graphics	Yes
Overclocking Support	Yes (P67, Z68)
TDP	6.1W
Launch Date	Q1'11
Supported Processor Series	2nd Generation Intel Core Processors
Release Date	Q1'11
