4.3 Configuration Settings
4.3.1 Configuration Jumpers/Switches
CAUTION: Do not move jumpers with the power on. To avoid damaging the
development board, always turn off the power and unplug the power cord from the
computer before changing jumper settings.
Table 20. Configuration Jumper/Switches
Reference Default Setting Comments PG
J4B1 (1-2) ON BOARD DDR3 THERMAL SENSOR 10
J4B3 (1-2) ON BOARD DDR3 THERMAL SENSOR 10
J1E1 (1-X) DISPLAY PORT PRESENCE 12
J1J1 (2-3) PM_EXTTS CONTROLLER 13
J5F2 (1-X) SRTC RST# 19
J5F3 (1-X) RTC RST# 19
J9F4 (1-2) RST SEL FOR PCIe Graphics 17
J8D3 (2-3) LVDS/EDP VDD EN 18
J8D2 (1-X) FLASH DESCRIPTOR OVERRIDE+___ 19
J9G4 (1-X) NO REBOOT 19
J6D1 (1-X) MPC SWITCH CONTROL 23
J8E2 (1-X) Test Detect 24
J8E3 (1-X) TEST SETUP 24
J9F3 (1-X) S_GPIO 24
J8G1 (1-X) BIOS RECOVERY 24
J9F5 (1-X) ICC ENABLE 24
J7D1 (2-3) PCIe SLOT4 POWER CONTROL 38
J7B2 (2-3) PCIe SLOT 3 POWER CONTROL 38
J9H5 (1-2) SATA PORT 0 DEVICE STATUS 39
J9H3 (1-2) E-SATA (PORT 4) DEVICE STATUS 39
J7H1 (1-2) SATA HOT PLUG REMOVAL DEFAULT 40
J8C4 (1-X) SPI PROGRAMMING 45
J8C5 (1-X) SPI PROGRAMMING 45
J8D1 All Open SPI PROGRAMMING 45
J6G1 (1-X) BCLK FREQUENCY SELECTION 46
J8C3 (1-2) SIO RESET 48
