Intel 6 SERIES

Development Board Summary
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
March 2011 User Guide
Document Number: 325208-001 49
Table 17. Development Board Components List - Top View
Item# Description Reference Designator
1 TPM header J9A1
2 Docking connector J9C1
3 DDI connector J8C2
4a PCIe slot3 J7C1
4b PCIe slot4 J7D2
5 PCIe slot5 J6C1
6a PCIe slot1 J6C2
6b PCIe slot2 J6D2
7 PEG slot J5C1
8 CPU U3E1
9 IMVP VR EU1B1
10 CPU XDP J1C1
11 Power on switch SW1E1
12 Reset switch SW1E2
13 Power Jack J1F2
14a Battery B J1H1
14b Battery A J1H2
15a eSATA (port4) J7J1
15b eSATA (port3) J6J1
16 SATA (direct connect-port0) J8J1
17 Embedded Controller U9G4
18 SATA ODD J9E7
19 LPC slot J8F2
20 LVDS connector J7D3
21 PCH U7F1
22 PCH XDP J8H3
23 USB2.0 FPIO headers J7H5, J7H6, J7H2, J8H2
24 SATA cable connect (port1) J7G1
25 ATX Power J5H2
26 RTC battery BT5G1
27 eDP connector J4E1
