3.6 Power Management
3.6.1 Power Management States
Table 16 lists the power management states that have been defined for the
development board. The board Controller Link (CL) operates at various power levels,
called M-states.
Table 16. Development Board Power Management States
State Description
G0/S0/C0 System Up and Running
G0/S0/C3 CPU Deep Sleep
G1/S3
Suspend To RAM (all switched rails are turned off)
G1/S4 Suspend To Disk
G2/S5 Soft Off
DSW
†
Deep Sleep
G3 Mechanical Off
