Intel 6 SERIES User Manual

About This Document
2
nd
Generation Intel
®
Core™ Processor with Intel
®
6 Series Chipset Development Kit
User Guide March 2011
12 Document Number: 325208-001
Acronym Definition
DMC Display Mini PCIe connector
DMI Direct Media Interface
DP Display Port
DPST Display Power Saving Technology
EC Embedded Controller
ECC Error Correcting Code
eDP Embedded Display Port
EEPROM Electrically Erasable Programmable Read-Only Memory
EHCI Enhanced Host Controller Interface
EM2 Eaglemont 2 card
EMA Extended Media Access
EMI Electro Magnetic Interference
eSATA External Serial Advanced Technology Attachment
ESD Electrostatic Discharge
EV Engineering Validation
EVMC Electrical Validation Margining Card
ERB Early Engineering Reference Board
FCBGA Flip Chip Ball Grid Array
FCIM Full Clock Integration Mode
FDD Floppy Disk Drive
FDI Flexible Display Interface
FIFO First In First Out - describes a type of buffer
FIR Fast Infrared
FPIO Front Panel IO
FS Full-speed. Refers to USB
FSB Front Side Bus
FWH Firmware Hub
GFX Graphics
GMCH Graphics Memory Controller Hub
GPIO General Purpose IO
Intel
®
HDA Intel
®
High Definition Audio
HDMI High Definition Media Interface
HPD Hot Plug Detect
HS High Speed. Refers to USB

Intel 6 SERIES Specifications

General

Chipset Series	6 Series
Code Name	Cougar Point
Max # of SATA 3.0 Ports	2
Max # of SATA 2.0 Ports	4
Socket Support	LGA1155
PCI Express Version	2.0
SATA Ports	6
USB Ports	14
Chipset	Intel H61 Express Chipset, Intel H67 Express Chipset, Intel P67 Express Chipset, Intel Z68 Express Chipset
Memory Support	DDR3
RAID Support	Yes
Integrated Graphics	Yes
Overclocking Support	Yes (P67, Z68)
TDP	6.1W
Launch Date	Q1'11
Supported Processor Series	2nd Generation Intel Core Processors
Release Date	Q1'11
