3.3.2. Restoring Board QSPI Flash with the Default Factory Image
1. Plug the QSPI flash card into the J3 slot.
2.
Ensure that MSEL[2:0] are [ON/ON/OFF] (Avalon streaming interface x8
configuration mode) before powering up the board.
3. Start the Quartus Prime Programmer GUI, and click Auto Detect to detect the
JTAG chain after the system MAX 10 is restored.
4. Attach the Avalon streaming interface x8 image (BTS/image/ES (PRD)/QSPI
folder) on the QSPI flash, which is under the system MAX 10 part.
5. Select programming options and click Program button.
Note: The QSPI flash is pre-programmed with GPIO image. It is overwritten by the Avalon
streaming interface x8 image after the steps above.
