A.1.2. Board Components
Table 6. Board Connector/Switch Description
Connector/Switch Description
J30 12 V AUX1 connector
J55 12 V AUX2 connector
J3 SDM connector
J38 FAN0 connector (Core FET fan)
J7 FMCA connector
J9 FMCB connector
J57 QSFP0 connector
J27 QSFP-DD0 connector
J22 QSFP-DD800 connector
J58 QSFP1 connector
J48 QSFP-DD1 connector
J77 SFP connector
J6 SI5395-2 IN1N connector
J4 SI5395-2 IN1P connector
J34 FAN1 connector (QSFP left fan)
J79 Temperature sensor I
2
C connector
J149 Current sensor I
2
C connector
J43 FAN2 connector (FPGA fan)
J37 MCIO connector
J5 DIMM connector
J44 FAN3 connector (QSFP right fan)
J45 OSFP connector
J67 QSFP-DD3 connector
J66 QSFP2 connector
J69 QSFP-DD2 connector
J25 10 MHz IN connector
J12 SI5395-1 IN1N connector
J8 SI5395-1 IN1P connector
J17 10 MHz OUT connector
J140 Clock I
2
C connector
J41 PMBUS connector
J21 ToD connector
J31 SI5518 SPI connectorconnector
J42 Clock I
2
C connector
continued...
