• F-Tile 5 (13B):
— 4 FGT Transceiver to channels to Mini Cool Edge IO (MCIO)
— 8 FGT transceiver channels to QSFP-DD connector
— 4 FHT transceiver channels fan out to Octal Small Form Factor Pluggable
(OSFP) connector
• F-Tile 6 (13C):
— 16 FGT channels to FMC+
— 4 FHT transceiver channels fan out to OSFP connector
• SR DDR4 2666 MT/s (× 72 w/ECC), 16 GB.
• SR DDR4 2666 MT/s (× 72 w/ECC), 16 GB 1 DPC Dual In-line Memory Modules
(DIMM) connector
Note: QSFP-DD400 and OSFP work up to 400 Gbps (50G x 8) PAM4 in DK-SI-AGI040FES.
QSFP-DD800 and OSFP work up to 800 Gbps (100G x 8) PAM4 in DK-SI-AGI040EA.
1.3. Box Contents
• Agilex 7 FPGA I-Series Transceiver Development Kit
• Single-rank DDR4 DIMM module
• Quad Serial Peripheral Interface (QSPI) flash daughter card
• USB2.0 Type B cable
• 1 × 240 W power adapter and NA/EU/JP/UK cords
Related Information
Agilex 7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit Website
1.4. Recommended Operating Conditions
Table 2. Recommended Operating Conditions
Operating Condition Range of Values
Ambient operating temperature range 0°C to 35 °C
ICC load current 50 A
ICC load transient percentage 269 A/uS
FPGA maximum power supported by active heat sink/fan 300 W
Related Information
Handling the Board on page 7
1. Overview
776646 | 2024.11.21
Agilex
™
7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit User Guide
Send Feedback
6
