A.5. General Input/Output
Table 9. MAX 10 and FPGA
Schematic Signal Name Description
F_GPIO0 The value of the filtered user_pb[0].
F_GPIO1 The value of the filtered user_pb[1].
F_GPIO2
Reserved
F_GPIO3
Reserved
F_GPIO4
Reserved
F_GPIO5
Reserved
F_GPIO6
Reserved
F_GPIO7
Reserved
F_GPIO8
Reserved
F_GPIO9
Reserved
F_GPIO10
Used for DIP Switch
F_GPIO11
Used for Switch Data Transfer
Table 10. System MAX 10
Schematic Signal Name Description
USER_PB0
User Push Button
USER_PB1
User Push Button
USER_SW0
User Switch
USER_SW1
User Switch
USER_SW2
User Switch
USER_SW3
User Switch
USER_SW4
User Switch
USER_SW5
User Switch
USER_SW6
User Switch
USER_SW7
User Switch
SYS_PWR_RSV3
Reserved GPIO between system MAX 10 and Power MAX 10
SYS_PWR_RSV2
Reserved GPIO between system MAX 10 and Power MAX 10
SYS_PWR_RSV1
Reserved GPIO between system MAX 10 and Power MAX 10
SYS_PWR_RSV0
Reserved GPIO between system MAX 10 and Power MAX 10
USER_LED0
User LED
USER_LED1
User LED
USER_LED2
User LED
