Note:
The unzipped folder name of JRE is jdk-11.0.xx+x-jre (for example,
jdk-11.0.14+9-jre), and you must rename it to jre. The unzipped
folder name of JFX is javafx-sdk-17.0.2, and you must rename it to
jfx.
2. On Linux system, Altera recommends you to unzip the files and rename the
folders using the following commands:
# unzip openjfx-17.0.2_linux-x64_bin-sdk.zip -d /opt/Java/
# tar zxvf OpenJDK11U-jre_x64_linux_hotspot_11.0.14_9.tar.gz -C /opt/Java/
# cd /opt/Java
# mv javafx-sdk-17.0.2 jfx
# mv jdk-11.0.14+9-jre jre
You have the following two directories on your Linux system:
•
/opt/Java/jre
•
/opt/Java/jfx
4.1.4. Setting Up the Quartus Prime Software for BTS Operation
You must install the Quartus Prime software to support the silicon on the development
kit. The recommended version is located in the README.txt file in the examples
\board_test_system directory. If you choose to install individual files, you must
install Agilex 7 Device Support.
The BTS communicates over JTAG to a test design running in the FPGA. The BTS
shares the JTAG with other applications such as the Nios
®
II JTAG Debug Module and
the Signal Tap Logic Analyzer. Altera recommends closing other applications before
using BTS, as the GUI is designed based on the Quartus Prime software.
The BTS relies on the Quartus Prime software's specific library. Before running the
BTS, open the Quartus Prime software to automatically set the environment variable
QUARTUS_ROOTDIR. You can also change it through Environment Variables in the
System Properties in Windows*. The BTS uses this environment variable to locate
the Quartus Prime library.
Related Information
Installing the Quartus Prime Pro Edition Software on page 8
4.1.5. Running the BTS GUI
With the power to the board off, follow these steps:
1. Connect the USB cable to your PC and the board.
2. Check the development board switches and jumpers are set according to your
preferences. Refer to Development Kit Setup. In most cases, BTS requires system
MAX 10 and Agilex 7 FPGA on the JTAG chain.
3. Check the external modules status: SFP/QSFP/OSFP/QSFPDD/QSFPDD800/FMC/
DIMM.
4. Turn on the board power switch.
