6. Custom Projects for the Development Kit
6.1. Add SmartVID Settings in the Quartus Prime QSF File
The Agilex 7 silicon that is assembled on this development kit enables the SmartVID
feature by default. To avoid the Quartus Prime software from generating an error due
to incomplete SmartVID settings, you must put constraints outlined below into the
Quartus Prime project QSF file. These constraints are designed for the LTC3888 PMIC.
Open your Quartus Prime project QSF file, and copy and paste constraint scripts into
the file. Ensure that there are no other similar settings with different values.
set_global_assignment -name PWRMGT_SLAVE_DEVICE_TYPE LTC3888
set_global_assignment -name PWRMGT_SLAVE_DEVICE0_ADDRESS 62
set_global_assignment -name PWRMGT_SLAVE_DEVICE1_ADDRESS 00
set_global_assignment -name PWRMGT_SLAVE_DEVICE2_ADDRESS 00
set_global_assignment -name ACTIVE_SERIAL_CLOCK AS_FREQ_100MHZ
set_global_assignment -name USE_PWRMGT_SCL SDM_IO0
set_global_assignment -name USE_PWRMGT_SDA SDM_IO12
set_global_assignment -name USE_CONF_DONE SDM_IO16
set_global_assignment -name VID_OPERATION_MODE "PMBUS MASTER"
set_global_assignment -name PWRMGT_VOLTAGE_OUTPUT_FORMAT "LINEAR FORMAT"
set_global_assignment -name PWRMGT_LINEAR_FORMAT_N "-12"
set_global_assignment -name PWRMGT_TRANSLATED_VOLTAGE_VALUE_UNIT VOLTS
6.2. Golden Top
You can use the Golden Top project as the starting point for your designs. It comes
loaded with constraints, pin locations, define I/O standard, direction, and general
termination. The DDR4 pin termination settings are not included. Refer to the DDR4
example designs for details.
