5. Development Kit Hardware and Configuration
The Agilex 7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit can support
multiple application scenarios and configuration modes. You need to either change the
hardware setting, re-program the system images, or both, for these cases.
Table 5. Supported Configuration Modes
S9 [1:4] MSEL [2:0] Configuration Mode
ON/OFF/OFF/X 001 AS – Fast mode (default setting)
ON/ON/OFF/X 011 AS – Normal mode
ON/ON/ON/X 111 JTAG
OFF/ON/ON/X 110 Avalon streaming x8
5.1. Configuring the FPGA Device by Active Serial (AS) Modes
(Default Mode)
Note: The default S9 and system MAX 10 image support AS configuration only.
1. Plug in the pre-programmed SDM QSPI flash daughter into J3.
2. Power on the board.
3. Observe that FPGA User_LED is turned on, and User_LED6 and User_LED7
blinked.
5.2. Configuring the FPGA Device by Avalon Streaming Modes
1. Set S9 to Avalon streaming interface x8 mode.
Note: The default system MAX 10 image supports Avalon streaming interface x8
configuration only.
2. Restart the board and program the flash device.
3. Observe that User_LED[0:5] are turned on, and User_LED6 and User_LED7
blinked.
