QSFP
Plug QSFP loopback module in J57/J58/J66 before you configure QSFP NRZ example
build through BTS GUI.
OSFP
Plug OSFP loopback module in J45 before you configure OSFP NRZ example build
through BTS GUI.
SFP
Plug four SFP loopback modules in J77 before you configure SFP NRZ example build
through BTS GUI.
DDR4 DIMM
Plug the DIMM module which is shipped alone with this development kit in J5.
