50 323094 Dev Kit Manual
Reference
Designator
Function
Default Setting
Optional Setting
J8G5
H8 MODE SELECTION
IN: Logic Low
OUT: Logic High
J8G4
H8 MODE SLECTION
OUT: Logic High
IN: Logic Low
J9F2
SMC/KSC
OUT: On board EC
Enabled
IN: On board EC Disabled
J8G6
KBC CORE DEBUG
OUT: Enabled
IN: Disabled
J9F1
THERM STRAP
OUT: Enabled
IN: Disabled
J9H1
SWITCHABLE GFX
OUT: Disabled
IN: Enabled
J9H4
SMC LID
OUT: Enabled
IN: Disabled
J9H2
VIRTUAL BATTERY
OUT: Enabled
IN: Disabled
J9G1
BOOT BLOCK PROGRAMMING
IN: Normal
OUT: Remote
Programming
J1C2
GFX VR ENABLE
OUT: Default
IN: Logic Low
J4J1
G3 SUPPORT
1-X: No After_G3
support
1-2: After G3 support with
ATX supply
2-3: After G3 Support
with AC brick
J1F1
FORCE POWER UP VBAT
OUT: Logic High
IN: Logic Low
J1E1
FORCE SHUT DOWN
OUT: Logic Low
IN: Logic High
J6A1
CON3_HDR
1-2: SML0_CLK Logic Low
2-3: SML0_DATA Logic
Low
J8H2
SGPIO
OUT: Logic High
1-2: Logic Low
2-3: Not used
J2B1
VID Override
OUT: Logic High
IN: Logic Low
15-16: Enable VID
Override
13-14: VID0
11-12: VID1
9-10: VID2
7-8: VID3
5-6: VID4
3-4: VID5
1-2: VID6
J2C1
GFX VID Override
OUT: Logic High
IN: Logic Low
15-16: VID6
13-14: VID5
11-12: VID4
9-10: VID3
7-8: VID2
5-6: VID1
3-4: VID0
