Intellian GX100NX - Network Configuration

106
Using AptusNX
Network Conguration
This function is available after performing the "iARM Save & Reboot" on page 93.
No. Item Description
1
Network
Conguration
Sets the BDT's Internal IP address and ports.
2
Management
Interface
Conguration
Sets the Management Port's network conguration. The Management Port is
located on the BDT front panel.
• IP Address: sets the network IP address (Factory default: 192.168.2.1).
• Subnet Mask: sets the subnet mask (Factory default: 255.255.255.0).
• Lease Start Address: sets the lease IP address start range.
• Lease End Address: sets the lease IP address end range.
• Lease Time: sets the lease IP address update time.
Click the "Apply" button to apply the settings to the system.
1
2
3
4
5
6
7
NOTE
NOTE
When clicking the "Apply" button after
editing the system settings, this pop-
up message will appear. If you want
to automatically save and reboot the
system, select the checkbox and click
the "Conrm" button.
