117
Appendix
Appendix B
Performing One Touch Comissioning
Ensure to perform One Touch Comissioning after the rst-time connection of the GX terminal and the BDT,
after cable replacement or band conversion. Take the following steps for One Touch Comissioning.
1. Connect an Ethernet cable from the Management LAN port on the front of the BDT to the LAN port of PC.
Management LAN Port
PC
(Not supplied)
2. Use the following IP address to access iDirect webpage.
• Default IP: 192.168.1.1
3. Login to the iDirect modem page using the below.
• ID: admin
• PW: iDirect123! (or P@55w0rd!)
4. Click "Commissioning", then the "Commissioning - One Touch Commissioning" page will appear.
5. Click "Start" button and monitor the progress of One Touch Commissioning.
6. When One Touch Commissioning is completed the "One Touch Commissioning Successfully Completed!"
message is displayed.
