111
Using AptusNX
No. Item Description
1
Mediator Setting
Intellian's new BDT has embedded Dual Antenna Mediator function, which can be
utilized to switch between two Intellian VSAT antenna systems simultaneously. When
one antenna is blocked by obstacles or has suddenly lost service, another antenna
will immediately provide fail-safe operation to maintain the highest levels of system
performance and reliability.
2
Mediator
Sets whether or not to use the dual antenna mediator function.
• Yes: enable the mediator function to use the Dual Antenna System. The
submenu is shown for detailed function settings.
• No: disable the mediator function.
Click the "Apply" button to apply the settings to the system. Then perform the
"iARM Save & Reboot" on page 93.
3
Antenna Active
This function is available in the Primary Antenna's AptusNX when both Primary
Role's BDT and Secondary Role's ACU are connected to the system.
Sets the method for selecting the active antenna. The active antenna (either
primary or secondary antenna) is communicating (Tx/Rx) with a satellite.
• Auto: this method is recommended. Automatically switch-over to the primary
or secondary antenna which is no blockages and no errors.
• Primary: manually switch-over to the primary antenna which is connected to
the primary role's BDT and the gyrocompass.
• Secondary: manually switch-over to the secondary antenna which is connected
to the secondary role's ACU.
Click the "Apply" button to apply the settings to the system.
Mediator Setting (Optional: For Dual Antenna System)
This function is available when using Dual Antenna System.
Primary Antenna's AptusNX View Secondary Antenna's AptusNX View
1
2
3
4
5
6
4
To Next Page
