Intellian GX100NX - ACU Diagnostics and Information

71
Operating ACU (Optional)
SNR F:20.119/18.250 RX:L TX:R
TRACKING 128.0 E
HDG:120.4
GPS:
A S
Executes antenna Diagnosis test and shows the real-time diagnosis result.
Diagnosis
DIAGNOSIS
DIAG ALL
DIAG : CODE 101
1 - - - O O 7 O O 10
- O 13 14 O O
Press
Move Key
Press
Select Key
Refer to the diagnosis codes for the test results.
DIAG : CODE 101
1 - - - O O 7 O O 10
- O 13 14 O O
2
1
ü Main Display
ü Diagnosis Display
ü Diagnosis Result Display
