72
Operating ACU (Optional)
No. Item Description
1
Diagnosis Code
Displays the diagnosis code.
Code Test
101 The data communication between the antenna and the
ACU is tested.
102 The azimuth axis is tested.
103 The elevation axis is tested.
104 The cross-level axis is tested.
105 Not Available
106 Not Available
107 The rate sensor is tested.
108 Not Available
109 Not Available
110 The LNB / NBD is tested.
111 The LNB pol motor is tested.
112 Not Available
113 The antenna power is tested.
114 The ACU power is tested.
115 Not Available
116 The home sensor is tested.
2
Diagnosis Result
• An example of diagnosis result:
1 - - - O O 7 O O 10
- O 13 14 O O
- ' - ' : The test was passed.
Code 102, 103, 104 and 111 were passed.
- Last 1 or 2 digits of diagnosis code : The test was failed.
Code 101, 107, 110, 113 and 114 were failed.
- ' O ' : The test was not performed.
Code 105, 106, 108, 109, 112, 115 and 116 were not performed.
Diagnosis Result of Code 101~110
Diagnosis Result of Code 111~116
To Next Page
