Installing Below Deck Unit (BDU)
Mounting BDT
Intellian supplies 19" Rack Mounting Brackets to mount the BDT in a rack.
19" Rack Mount Type
The BDT should be installed using the two supplied 19" Rack Mounting Brackets. Using the Flat Head Screw
supplied, attach the mounting brackets to the sides of the BDT. Place the BDT in the location where it is going
to be installed. Connect the cables to the rear of the BDT.
WARNING
WARNING
Ensure that the cables connected to the BDT are long enough to prevent damage when the BDT is
pulled out from the rack.
Figure: 19" Rack Mount Type BDT
