17BChapter 18: Using the web browser
TruVision DVR 44HD User Manual 125
Figure 34: Browser playback page
. Calendar: Selected day is highlighted.
. Search: Click to start searching recorded files for the selected camera.
. Display format: Click to change the display format in the viewer: single view or multiview display.
. Timeline: The timeline moves left (oldest video) to right (newest video). Click a location on the timeline to
move the cursor to where you want playback to start.
. Playback control toolbar:
Reverse: Click to reverse playback.
Start/stop: Start or stop playback.
Stop playback. Timeline jumps back to 00:00:00 time (midnight) of the previous day.
Speed down: Click to scroll through the different speeds available: single frame, 1/8 speed, ¼
speed, ½ speed, normal, X2 speed, X4 speed, X8 speed, maximum speed. Current speed is
displayed under the camera name on top right of window.
Speed up: Click to scroll through the different speeds available: single frame, 1/8 speed, ¼ speed,
½ speed, normal, X2 speed, X4 speed, X8 speed, maximum speed. Current speed is displayed
under the camera name on top right of window.
Single frame: Click to play back one frame at a time.
Stop streaming: Stop streaming from all cameras.
. Audio and video control toolbar:
Digital Zoom. Access digital zoom. See “Digital zoom in playback” on page 41 for further
information.
Text insertion: Click to enable/disable POS/ATM text display in playback.
Snapshot: Capture a snapshot of the video.
