Interlogix TruVision DVR 44HD - Controlling a Camera

22BAppendix E: KTD-405 keypad
TruVision DVR 44HD User Manual 147
Task Keypad action Further information
Jump 30 seconds forwards or
backwards during playback
Press and hold esc and then
press the up/down arrow
buttons or move the joystick to
the left/right.
Controlling a camera
When setting up and controlling your cameras in zone mode, refer to Table 23 below for the list
of default PTZ addresses associated with a zone ID. This value is automatically populated in
the system. You can modify the PTZ address in the PTZ menu to meet customer requirements
(see “Configuring PTZ settings” on page 71).
Table 23: Default PTZ camera addresses by zone ID
Camera
input
Zone ID of the recorder
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480
2
1 33 65 97 129 161 193 225 257 289 321 353 385 417 449 481
3
2 34 66 98 130 162 194 226 258 290 322 354 386 418 450 482
4
3 35 67 99 131 163 195 227 259 291 323 355 387 419 451 483
5
4 36 68 100 132 164 196 228 260 292 324 356 388 420 452 484
6
5 37 69 101 133 165 197 229 261 293 325 357 389 421 453 485
7
6 38 70 102 134 166 198 230 262 294 326 358 390 422 454 486
8
7 39 71 103 135 167 199 231 263 295 327 359 391 423 455 487
9
8 40 72 104 136 168 200 232 264 296 328 360 392 424 456 488
10
9 41 73 105 137 169 201 233 265 297 329 361 393 425 457 489
11
10 42 74 106 138 170 202 234 266 298 330 362 394 426 458 490
12
11 43 75 107 139 171 203 235 267 299 331 363 395 427 459 491
13
12 44 76 108 140 172 204 236 268 300 332 364 396 428 460 492
14
13 45 77 109 141 173 205 237 269 301 333 365 397 429 461 493
15
14 46 78 110 142 174 206 238 270 302 334 366 398 430 462 494
16
15 447 79 111 143 175 207 239 271 303 335 367 399 431 463 495
17
16 48 80 112 144 176 208 240 272 304 336 368 400 432 464 496
18
17 49 81 113 145 177 209 241 273 305 337 369 401 433 465 497
19
18 50 82 114 146 178 210 242 274 306 338 370 402 434 466 498
20
19 51 83 115 147 179 211 243 275 307 339 371 403 435 467 499
21
20 52 84 116 148 180 212 244 276 308 340 372 404 436 468 500
22
21 53 85 117 149 181 213 245 277 309 341 373 405 437 469 501
23
22 54 86 118 150 182 214 246 278 310 342 374 406 438 470 502
