9BChapter 10: Camera setup
68 TruVision DVR 44HD User Manual
Full
-screen Monitoring When an alarm is triggered, the monitor (VGA or HDMI) displays an
image in live view mode. For alarms that are triggered simultaneously,
images display one at a time every 10 seconds (default dwell time).
Change the desired sequence dwell time under Display
Settings>Dislpay>Sequence Dwell Time. When the alarm stops,
cycling of the images stops and you return to live view mode.
Enable Alarm Audio
Trigger an audible beep when a line crossing detection alarm is
detected.
Notify
Alarm Host Send an exception or alarm signal to remote management software
when a line crossing detection alarm occurs.
Send Email
Send an email to a specified address when there is a line crossing
detection alarm.
Note: You must configure email settings before enabling this option.
See “E-mail settings” on page 81 for
further information. If you want to
send the event snapshot together with the email, check the “Attached
Snapshot” option.
Upload Snapshot
to FTP
Capture the image when an alarm is triggered and upload the picture
to NAS or FTP server.
Note: To upload the snapshot to NAS, you must first configure the
NAS settings. See “Add a network storage system” on page 109 for
further information.
To upload the snapshot to an FTP, you must first configure the FTP
settings. See “Configure an FTP server to store snapshots” on page
82.
To upload the snapshot to FTP and NAS when motion detection or
an
alarm input is triggered, you must also enable Upload Snapshots to
FTP under the alarm input actions. See “Alarm notification types” on
page 93 for further information.
Trigger Alarm Output
Trigger external alarm outputs when an event occurs. Check “Select
All” or each individual alarm output.
Note: This option is only supported by cameras that support alarm
output.
12. Click Apply to save changes.
13. Click Exit to return to live view.
Privacy mask
You can define an area on screen to remain hidden from view and recording. For example, you
can choose to block the view of a camera when overlooking residential premises. This hidden
area is referred to as privacy masking. Privacy masking cannot be viewed in live view or
recorded mode, and appears as a black area on the video image.
Up to four privacy masks can be defined for one analog camera. For IP cameras, the amount of
privacy masks is determined by the amount supported by the camera.
