9BChapter 10: Camera setup
70 TruVision DVR 44HD User Manual
5. Select the recording schedules for the tamper.
Click Actions and then select the Arming Schedule tab to select the day of the week and
the time periods during the day when motion can be recorded. You can schedule up to eight
time periods in a day. Default is 24 hours.
Click Apply to save the settings. Click Copy to copy the settings to other days of the week
and holiday period.
Note: The time periods defined cannot overlap.
6. Select the response method to an external alarm.
Click Actions and then select the Actions tab to select the method by which you want the
recorder to notify you of the alarm: Full-screen monitoring, Enable alarm audio, Notify alarm
host, Send email, and Trigger alarm output. See page 93 for the list of alarm notification
types.
Click Apply to save settings and then OK to return to the main window.
7. Click Exit to return to live view.
Restricted access camera
Restricted access cameras are cameras that are only visible to specific users.
There may be occasions when you want to control who can see a camera image on a local
monitor, such as if there is a camera located in a changing room. The recorder lets you select
which camera (or cameras) is not displayed on the local monitor unless the user is logged in
and has permission to view the camera images. A restricted access camera is not displayed on
screen when no user is logged in. Instead a person walking by sees a black screen. See
Figure 23 below.
Figure 23: Example of a restricted access camera image
