9BChapter 10: Camera setup
TruVision DVR 44HD User Manual 67
Figure 22: Intrusion detection window
To define line crossing detection:
1. From the menu toolbar, click Camera Setup > VCA(SMD) > VCA.
2. Select the camera to detect line crossing motion. Each camera must be set up individually.
3. Under “Type”, select Intrusion Detection and check Enable.
4. Under “Intrusion Region”, select the desired region number. You can create up to four
different regions for a camera.
5. Set the sensitivity level between 1 and 100. Default is 50.
6. Set the percentage level between 1 and 100. Default is 1.
7. Set the time threshold level between 1 and 10. Default is 0.
Note: Click Restore to return the sensitivity, percentage and time threshold values to
default.
8. To set a region, click . The cursor changes to a pen symbol.
Click where you want the region to start on screen and click two other points of the desired
region. A blue quadrilateral region appears on screen.
Click to select the full screen.
Note: Click to delete the line.
9. Specify the channels triggered when a line crossing detection alarm is triggered. Click
Settings > Trigger Channel and check the cameras that will start recording. Click Apply
and OK.
10. Specify the schedule during which a line crossing detection alarm can be triggered. Click
Settings > Arming Schedule. Select the day of the week and the time.
11. Specify the action when a line crossing detection alarm is triggered. Click Settings >
Actions and check one or more response methods.
