Interlogix TruVision DVR 44HD - Page 57

: Display settings
TruVision DVR 44HD User Manual 55
The camera order in the different views is consistent. This means that if Channel 2 is the first
camera shown in the single camera view then it will also be the top left camera of the 4-channel
view.
You can switch the channel of a camera with that of another camera in the system. This lets
you, for example, have the images of camera 1 appear on channel 10, and the images of
camera 10 appear on channel 1. This feature is useful when you want to watch the sequence of
images from specific cameras so that they are next to each other on-screen.
See Figure 18 below. Each video tile displays both the order of the camera on screen and the
camera number.
Figure 18: Camera layout window
Multiview layout
selection bar
Camera order in
the sequence
Camera number
selection
