9BChapter 10: Camera setup
72 TruVision DVR 44HD User Manual
Figure 24: PTZ configuration window
Table 13: Description of the PTZ configuration window
Name Description
1
. Save preset Saves preset.
2
. Call preset Calls up pre-existing preset.
3
. Shadow tour toolbar
Starts recording the shadow tour.
Saves the shadow tour.
Starts the selected shadow tour.
Deletes the selected shadow tour.
4
. Preset tour toolbar
Adds a step to a selected preset tour.
Starts the selected preset tour.
Stops the selected preset tour.
Deletes all the preset tour steps.
Scroll up the list.
Scroll down the list.
To set up a preset:
1. From the menu toolbar, click Camera Setup > PTZ Preset/Tours.
2. Use the directional, zoom, focus and iris buttons to position the analog camera in the
desired preset location.
3. Check Save Preset and enter a preset number. The preset is enabled and stored in the
camera.
