76 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 7—Print Mechanism
Front ribbon
break shaft
Ribbon motor
Guide link
Print mechanism in an EasyCoder PF4i Compact Industrial
(doors omitted)
Platen roller
Liner drive roller
Tear bar
Printhead ribbon
break shaft
Printhead cable
