Intermec EasyCoder PF4i Service Manual

2 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 1—Models and Options
1.1 Identification
EasyCoder PF2i
The EasyCoder PF2i comes either as a dedicated direct thermal printer or,
optionally, as a combined direct thermal/thermal transfer printer. It can use
media up to 60 mm (2.36 inches) wide and has a print width of 56 mm
(2.2 inches). It has an 8 dots/mm (203.2 dpi) printhead.
The printer runs either Intermec Fingerprint Programming Language (FP)
v8.10 (or later) or Intermec Programming Language (IPL) v2.10 or later.
Externally, the difference is visible on the keyboard overlay. Fingerprint
printers have 22 keys and IPL printers have 7 keys.
Keyboard shows printer model
Narrow front on side door
Keyboard shows printer model
Narrow front on side door
Keyboard shows printer model
Narrow front on side door
EasyCoder PF2i (Fingerprint version)
EasyCoder PF2i (IPL version)

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
