Intermec EasyCoder PF4i Service Manual

Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 163
This chapter describes the various communication interfaces for the Easy-
Coder PF2i, PF4i, and PF4i Compact Industrial printers. However, some
interfaces are not supported by the Intermec Programming Language (IPL)
even though the connecors are present.
The chapter describes three categories:
• Standard built-in interfaces
RS-232 interface
USB interface (not supported by IPL)
Bar code wand interface (not supported by IPL)
• Optional interface boards
Serial/Industrial interface board (not supported by IPL)
Double Serial interface board (not supported by IPL)
IEEE 1284 Parallel interface board
• EasyLAN interface boards
EasyLAN Ethernet interface
EasyLAN Wireless interface
The printers can—in addition to the standard built-in interfaces—also
be fi tted with one or two optional interface boards and one EasyLAN
interface board.
Note: Device designations, such as "uart1:", "usb1:", or "net1:", only
apply to Fingerprint, not to IPL.
14
Interfaces

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
