Intermec EasyCoder PF4i Service Manual

Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 15
Chapter 1—Models and Options
Printing
Print Technique Direct Thermal and Thermal Transfer
Printhead Resolution 8 dots/mm (203.2 dpi)
11.81 dots/mm (300dpi)
Standard
Option (not IPL)
Print Speed (variable) 100 to 200 mm/sec. (approx. 4 to 8 in./sec.)
100 to 150 mm/sec. (approx. 4 to 6 in./sec.)
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Width (max) 104 mm (4.095 in.) = 832 dots
105.7 mm (4.161 in.) = 1248 dots
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Length (max) 32767 dots = 409.5 cm (161.25 in.)
1
Media Width (min/max) 25 to 114.3 mm (1.00 to 4.5 in.) Standard edge guide
Media Width (min/max) 40/80 to 114.3 mm (1.57/3.15 to 4.5 in.) Quick-Load guides
Media Roll Diameter (max) 152 mm (6 in.)
213 mm (8.38 in.)
Long side door
Megatop
Media Roll Core Diameter 38 to 40 mm (1.5 in.) or 76 mm (3 in.)
Ribbon Width (min/max) 25 to 110 mm (1 to 4.33 in.)
Ribbon Roll Diameter, Outer (max) 65 mm (2.44 in.) 240-300 m (787-985 ft)
Ribbor Roll Core Diameter, Inner 25.4 mm (1 in.)
Print Directions 4
Modes of Operation
Tear Off (Straight-through) Yes
Cut Off Optional With paper cutter
Peel Off (Self-strip) Optional With liner takeup unit
Firmware (Fingerprint)
Operating System Intermec Fingerprint v8.10 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Built-in scaleable fonts (std) 15 Unicode fonts
2
Built-in bar code symbologies (std) 45
Startup Program (std) Intermec Shell v8.0
Firmware (IPL)
Operating System IPL v2.10
Built-in scaleable fonts (std) 13 scaleable + 21 simulated bitmap
Built-in bar code symbologies (std) 31
Physical Measures
Dimensions (W×L×H) 244×405×178 mm (9.61×15.93×7.00 in.) With long side door
253×447×178 mm (9.96×17.60×7.00 in.) With paper cutter
244×475×225 mm (9.61×18.70×8.86 in.) With 8-in. Megatop
Weight (excluding media) approx. 7 to 8 kg (15.5 to 17.7 pounds) Depending on model
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Humidity 20 to 80% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 2 sockets (for 4 or 8 MB each) Std. 1 × 4MB
On-board SDRAM SIMM 1 socket (for 8 or 16 MB) Std. 1 × 8MB
1.4 EasyCoder PF4i Compact Industrial Specifications

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
