Chapter 1—Models and Options
Power Supply
AC Voltage 90 to 265 VAC, 45 to 65Hz
PFC Regulation IEC 61000-3-2
Power Consumption Standby 15W; Peak 300W
Sensors
Label Gap/Black Mark/Out of Media Yes 5 fi xed positions
Printhead Lifted Yes
Ribbon End/Ribbon Low Yes (thermal transfer model only)
Controls
Control Lamps 3
Display 2 × 16 character LCD with background light
Keyboard Fingerprint: 22 keys; IPL: 7 keys Membrane-switch type
Print or Feed/Pause button 1
Beeper Yes
Data Interfaces
Serial 1×RS-232 + 1×USB USB not supp. by IPL
Bar Code Wand 1 Not supported by IPL
Connection for Interface Boards 1 + 1 1 EasyLAN + 1 other
Memory Card Adapter 1 CompactFlash cards
Accessories and Options
Special printheads 8 dots/mm: Thick media
11.81 dots/mm: Standard and Thick media
203.2 dpi
300 dpi (not IPL)
Paper Cutter Option For cut-off operation
Paper Cutter Tray Option For cut-off operation
Integral Self-strip Unit w. Liner Takeup Option For peel-off operation
Rotating Media Supply Hub Option
3-inch Adapter Option For media supply hub
Printhead Spring Kit Option For vertical installation
Short Side Door Option
3
Long Side Door Option
3
Long side door with 8-inch Megatop Option
3
Label Taken Sensor Option
Real Time Clock Option (not IPL) 10+ years life
RS-232 Interface Cable Option
Parallel Interface Cable Option
IEEE 1284 Parallel Interface Board Option
Double Serial Interface Board Option (not IPL)
Serial/Industrial Interface Board Option (not IPL)
EasyLAN Ethernet Interface Option Model EasyLAN100i2
EasyLAN Wireless Interface Option Model Wireless100i2
External Alphanumeric Keyboard Option (not IPL)
CompactFlash Cards Option 8MB to 1GB; not CF+
Compact Flash Card Protection Plate Option
1
/. The max. print length is also restricted by the amount of free SDRAM memory.
2
/. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3
/. Type of door fi tted at delivery depends on model.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
