Intermec EasyCoder PF4i Service Manual

Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 13
Chapter 1—Models and Options
Printing
Print Technique Thermal Transfer and/or Direct Thermal
Printhead Resolution 8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Standard
Option (not IPL)
Print Speed (variable) 100 to 200 mm/sec. (approx. 4 to 8 in./sec.)
100 to 150 mm/sec. (approx. 4 to 6 in./sec.)
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Width (max) 104 mm (4.095 in.) = 832 dots
105.7 mm (4.161 in.) = 1248 dots
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Length (max) 32767 dots = 409.5 cm (161.25 in.)
1
Media Width (min/max) 25 to 114.3 mm (1.00 to 4.5 in.) Standard edge guide
Media Width (min/max) 40/80 to 114.3 mm (1.57/3.15 to 4.5 in.) Quick-Load guides
Media Roll Diameter (max) 213 mm (8.38 in.) Short door/no takeup
Media Roll Core Diameter 38 to 40 mm (1.5 in.) or 76 mm (3 in.)
Ribbon Width (min/max) 25 to 110 mm (1 to 4.33 in.)
Ribbon Roll Diameter, Outer (max) 65 mm (2.44 in.) 240-300 m (787-985 ft)
Ribbor Roll Core Diameter, Inner 25.4 mm (1 in.)
Print Directions 4
Modes of Operation
Tear Off (Straight-through) Yes
Cut Off Optional With paper cutter
Peel Off (Self-strip) Optional With liner takeup unit
Firmware (Fingerprint)
Operating System Intermec Fingerprint v8.10 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Built-in scaleable fonts (std) 15 Unicode fonts
2
Built-in bar code symbologies (std) 45
Startup Program (std) Intermec Shell v8.0
Firmware (IPL)
Operating System IPL v2.10
Built-in scaleable fonts (std) 13 scalable + 21 simulated bitmap
Built-in bar code symbologies (std) 31
Physical Measures
Dimensions (W×L×H) 244×397×178 mm (9.61×15.63×7.00 in.)
253×447×178 mm (9.96×17.60×7.00 in.)
244×471×225 mm (9.61×18.54×8.86 in.)
With long side door
With paper cutter
With 8-in. Megatop
Weight (excluding media) approx. 7 to 8 kg (15.5 to 17.7 pounds)
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Humidity 20 to 80% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 2 sockets (for 4 or 8 MB each) Std. 1 × 4MB
On-board SDRAM SIMM 1 socket (for 8 or 16 MB) Std. 1 × 8MB
1.3 EasyCoder PF4i Specifications

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
