Intermec EasyCoder PF4i Service Manual

256 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Appendix B—Firmware Upgrading
Note: A special case is if the CompactFlash card already has a Fingerprint
fi rmware. Inserting such card will always install fi rmware in the printer
according to CompactFlash card. However, perhaps you like to install a
later fi rmware version picked from the web. If so, proceed like this:
1 Insert the CompactFlash card with a upgrade fi rmware on. Switch on
and wait for a completed upgrade and the normal startup of the printer
so you are in Fingerprint mode.
2 Activate the Shell program from "/rom" like this:
LOAD "/rom/SHELLXP.PRG"
MERGE "/rom/ERRHAND.PRG"
RUN
3 In Shell, select the option “UPDATE: COMPACT FLASH?” and press
<Enter>.
4 Send the .bin or .uff fi le from the host using zmodem.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
