Interroll MultiControl Instruction Manual

Safety related information
Version 3.0 (08/2018)
4 Translation of original instruction manual
2 Safety related information
2.1 State of the art
The Interroll MultiControl is built in compliance with applicable standards and state of the art
technology and is delivered safely. Nevertheless, hazards can arise during use.
Failure to follow the instructions in this manual may result in life-threatening injuries.
In addition, the local accident prevention regulations and general safety regulations applicable to
the area of application must be complied with.
2.2 Intended use
The MultiControl may only be used in industrial environments for industrial purposes within the
specified performance limits specified in the technical data.
It controls up to four Interroll RollerDrive or VDC Motors and must be integrated into a conveyor
unit or conveyor system before commissioning.
A corresponding adapter must be used to connect a VDC motor.
Areas of application
The following areas of application are possible:
Using a
PLC
Function of a PLC
Function of the MultiControl
No
None
Realization of the ZPA Logic
Yes
- Influencing the ZPA logic
- Tracking of conveyed items
- Fault diagnosis
Implementation of PLC specifications
Yes
- The PLC program controls all
connected RollerDrive
- Tracking of conveyed items
- Fault diagnosis
Function as network card
Sends the state of all Sensors,
RollerDrive and, if necessary, error
information to the PLC

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
