Interroll MultiControl Instruction Manual

Product information
Version 3.0 (08/2018)
Translation of original instruction manual 13
3.5 Technical Data
Rated voltage logic and sensors (L1)
24 V DC, Protective Extra Low Voltage PELV
Voltage range L1
22 to 26 V DC
Rated voltage RollerDrive (L2)
24 V DC, Protective Extra Low Voltage PELV
Voltage range L2
22 to 28 V DC
Current consumption
Logic supply voltage:
MultiControl: max. 0,2 A + connected
sensors/actors = max. 1,6 A
Motor supply voltage:
RollerDrive rated current: 4 x 1,75 A = 7 A
RollerDrive start up current: 4 x 3,5 A = 14 A
Protection rate
IP54 (not UL approved)
Pollution degree
2
Weight
500 g (incl. baseplate)
Ambient temperature in operation
-30 C bis +40 C
Ambient temperature during
transport and storage
-40 C bis +80 C
Max. temperature change
1 K/min, 3 h, 2 cycles
Max. relative humidity
93 % at +40 C, 14 days, not condensing
Max. installation height above sea
level
Max. 2000 m
The installation in systems at an altitude above
2000 m is possible in principle. However, it may
result in a reduction of the performance values.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
