Troubleshooting
Version 3.0 (08/2018)
50 Translation of original instruction manual
LED of the connections
LED
State
Meaning
Sensor 1
Sensor 2
Sensor 3
Sensor 4
On
Logical state of the displayed sensor:
Positive logic configured and logical "1" (PNP 24 V, NPN 0 V)
at input - or - Negative logic configured and logical „0“ at
input
I/O 1
I/O 2
I/O 3
I/O 4
On
Logical state of the displayed input/output:
Positive logic configured and logical "1" (PNP 24 V, NPN 0 V)
at input - or - Negative logic configured and logical „0“ at
input
RD 1
RD 2
RD 3
RD 4
On
Displayed RollerDrive gets nominal value
Link/Act A
Link/Act B
On or
flashing(for
EtherCAT
bus type)
Displayed network connection is OK
8.2 Troubleshooting
The MultiControl is a complex system. There are many correlations between all participants in the
system. In such a system, of course, errors can also arise, which can result either from the
conveying processes or from the interaction of the individual components. Not all errors can be
displayed in detail and a correlation between the location and the location of the display is not
always possible. A better fault diagnosis is possible by the PLC.
If troubleshooting is not successful, contact Interroll Support and have the following information at
hand:
Serial number of the affected MultiControl
Information about the configuration
Information on the LED displays
Information on error codes
