Interroll MultiControl Instruction Manual

Initial start up and operation
Version 3.0 (08/2018)
Translation of original instruction manual 27
Homepage "MultiControl Overview"
Use the menu in the left-hand side area to navigate through the additional information and
settings.
The following information is displayed on the home page:
• Information about the set bus system
• Information about the last error occurred
• Information about the selected application program
All illustrated pages in this chapter reflect the respective factory settings.
➢ To exit the user interface click on "Log Out" (not necessary, if the MultiControl is restarted).

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
