Interroll MultiControl Instruction Manual

Initial start up and operation
Version 3.0 (08/2018)
40 Translation of original instruction manual
Service - Change Password
➢ To change the password, enter the old password and twice the new password and transfer
to the MultiControl by pressing the "Submit" button.
The user name cannot be changed.
Loading the factory settings resets the changed password to default.
Service - Factory Reset
Loading the factory settings:
➢ Selection „Yes“
➢ Button „Submit“
NOTICE
Destruction of the MultiControl due to premature shutdown of the supply voltage
➢ Ensure that the power supply is uninterrupted until the restart is complete. Duration
of the process about two minutes.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
