Interroll MultiControl Instruction Manual

Initial start up and operation
Version 3.0 (08/2018)
Translation of original instruction manual 33
Function
Command
Control Output 3
Zone 3 occupied
Control Output 4
Zone 4 occupied
Control Output 5 - 8
Without function
Handshake In Up
Handshake signals to neighbouring ZPA modules
Handshake In Down
Handshake In Left
Handshake In Right
Handshake Out Up
Handshake Out Down
Handshake Out Left
Handshake Out Right
VDC Motor #1 Error In
Error input VDC motor
VDC Motor #2 Error In
VDC Motor #1 Direction Out
Direction output VDC motor
VDC Motor #2 Direction Out
VDC Motor #1 Step Pulse Out
Step pulse output VDC motor
VDC Motor #2 Step Pulse Out
The functions don’t affect the "I/O Device" control program.
Depending on the selected control program, the functions vary (see the description
of the control programs in the supplementary document "Interroll MultiControl -
Operating and Programming").
To apply the changed parameters to the MultiControl, press the "Submit" button.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
